 mm |
| |
|
型号 |
公称扭矩
Tn （N.m） |
瞬时最扭矩T
max
N.m |
许用转速
r/min |
轴孔直径
d |
轴孔长度
L |
D |
B |
转动惯量
（kg.m2） |
|
钢 |
铁 |
钢 |
铁 |
|
UL1 |
10 |
31.5 |
5000 |
3500 |
11-18 |
11-16 |
22-42 |
80 |
20 |
0.0003 |
|
UL2 |
25 |
80 |
5000 |
3000 |
14-22 |
14-20 |
32-52 |
100 |
26 |
0.0008 |
|
UL3 |
63 |
180 |
4800 |
3000 |
18-25 |
18-22 |
30-62 |
120 |
32 |
0.0022 |
|
UL4 |
100 |
315 |
4500 |
3000 |
20-30 |
20-25 |
38-82 |
140 |
38 |
0.0044 |
|
UL5 |
160 |
500 |
4000 |
3000 |
24-35 |
24-30 |
38-82 |
160 |
45 |
0.0084 |
|
UL6 |
250 |
710 |
3600 |
2500 |
28-40 |
28-35 |
44-112 |
180 |
50 |
0.0146 |
|
UL7 |
315 |
900 |
3200 |
2500 |
32-48 |
32-42 |
60-112 |
200 |
56 |
0.029 |
|
UL8 |
400 |
1250 |
3000 |
2000 |
38-50 |
38-45 |
60-112 |
220 |
63 |
0.0448 |
|
UL9 |
630 |
1800 |
2800 |
2000 |
42-60 |
42-55 |
84-142 |
250 |
71 |
0.0898 |
|
UL10 |
800 |
2240 |
2400 |
1600 |
45-70 |
45-65 |
84-142 |
280 |
80 |
0.1596 |
|
UL11 |
1000 |
2500 |
2100 |
1600 |
50-75 |
50-65 |
84-142 |
320 |
90 |
0.2792 |
|
UL12 |
1600 |
4000 |
2000 |
1600 |
55-85 |
55-80 |
84-172 |
360 |
100 |
0.5356 |
|
UL13 |
2500 |
6300 |
1800 |
1600 |
63-95 |
63-95 |
104-172 |
400 |
110 |
0.896 |
|
UL14 |
4000 |
10000 |
1600 |
1400 |
75-110 |
75-110 |
107-212 |
480 |
130 |
2.2616 |
|
UL15 |
6300 |
14000 |
1200 |
1120 |
85-125 |
90-125 |
132-212 |
560 |
150 |
4.6456 |
|
UL16 |
10000 |
20000 |
1000 |
1000 |
100-140 |
100-140 |
167-252 |
630 |
180 |
8.0924 |
|
UL17 |
61000 |
31500 |
900 |
850 |
120-160 |
130-160 |
167-302 |
750 |
210 |
20.0176 |
|
UL18 |
25000 |
50000 |
800 |
750 |
140-180 |
150-170 |
202-302 |
900 |
250 |
34.053 |
|
| |
|
