型号 |
公称扭矩
Tn N.m |
许用转速
r/min |
轴孔直径 |
轴孔长度
L |
D |
D1 |
D2 |
D3 |
转动惯量
(kg.m2) |
|
dz |
d1,d2 |
|
NGCL1 |
355 |
4000 |
20-35 |
20-35 |
38-82 |
103 |
71 |
50 |
160 |
0.07-0.071 |
|
NGCL2 |
630 |
4000 |
25-45 |
25-45 |
44-112 |
115 |
83 |
60 |
160 |
0.079-0.083 |
|
NGCL3 |
1000 |
3800 |
30-55 |
28-56 |
44-110 |
127 |
95 |
75 |
200 |
0.181-0.187 |
|
NGCL4 |
1600 |
3800 |
40-65 |
38-65 |
60-142 |
149 |
116 |
90 |
200 |
0.225-0.246 |
|
NGCL5 |
2800 |
3000 |
45-75 |
40-75 |
84-142 |
167 |
134 |
105 |
250 |
0.58-0.609 |
|
NGCL6 |
4500 |
3000 |
50-90 |
45-90 |
84-172 |
187 |
153 |
125 |
250 |
0.714-0.795 |
|
NGCL7 |
6300 |
2400 |
60-100 |
50-100 |
84-212 |
204 |
170 |
140 |
315(300) |
1.17-1.388 |
|
NGCL8 |
9000 |
1900 |
70-110 |
55-110 |
82-212 |
230 |
186 |
155 |
400 |
3.747-4.072 |
|
NGCL9 |
14000 |
1500 |
80-130 |
60-130 |
107-252 |
256 |
212 |
180 |
500 |
9.427-9.847 |
|
NGCL10 |
20000 |
1200 |
80-150 |
65-150 |
107-252 |
287 |
239 |
200 |
630(600) |
28.238-29.248 |
|
NGCL11 |
31500 |
1050 |
100-170 |
70-170 |
107-302 |
325 |
276 |
235 |
710(700) |
44.309-47.08 |
|
NGCL12 |
45000 |
1050 |
100-200 |
75-200 |
107-352 |
362 |
313 |
270 |
710(700) |
47.88-53.69 |
|
NGCL13 |
63000 |
950 |
150-220 |
150-220 |
202-352 |
412 |
350 |
300 |
800 |
82.7-86.67 |
|
NGCL14 |
100000 |
950 |
170-220 |
170-250 |
242-410 |
462 |
420 |
335 |
800 |
99.1-105.9 |
|
| |
|
