型 号 |
公称扭矩
Tn N.m |
许用转速
r/min |
轴孔直径
d1,d2,dz |
轴孔长度
L |
D |
D1 |
D2 |
转动惯量
kg.m2 |
|
G1CL1 |
630 |
4000 |
16-38 |
38-82 |
125 |
95 |
60 |
0.009 |
|
G1CL2 |
1120 |
4000 |
25-48 |
44-112 |
144 |
120 |
75 |
0.02 |
|
G1CL3 |
2240 |
4000 |
30-60 |
60-142 |
174 |
140 |
95 |
0.047 |
|
G1CL4 |
3550 |
3600 |
32-67 |
60-142 |
196 |
165 |
115 |
0.091 |
|
G1CL5 |
5000 |
3300 |
40-80 |
84-172 |
224 |
183 |
130 |
0.167 |
|
G1CL6 |
7100 |
3000 |
48-90 |
84-172 |
241 |
200 |
145 |
0.267 |
|
G1CL7 |
10000 |
2680 |
60-100 |
207-217 |
260 |
230 |
160 |
0.453 |
|
G1CL8 |
14000 |
2500 |
65-110 |
107-212 |
282 |
245 |
175 |
0.646 |
|
G1CL9 |
18000 |
2350 |
75-125 |
107-212 |
314 |
270 |
200 |
1.036 |
|
G1CL10 |
31500 |
2150 |
80-140 |
132-252 |
346 |
300 |
220 |
1.88 |
|
G1CL11 |
40000 |
1180 |
100-160 |
167-302 |
380 |
330 |
260 |
3.28 |
|
G1CL12 |
56000 |
1680 |
120-180 |
167-302 |
442 |
380 |
290 |
5.08 |
|
G1CL13 |
80000 |
1530 |
140-200 |
202-352 |
482 |
420 |
320 |
10.06 |
|
G1CL14 |
112000 |
1300 |
160-220 |
242-352 |
520 |
465 |
360 |
16.774 |
|
G1CL15 |
160000 |
1180 |
190-250 |
282-410 |
580 |
510 |
400 |
26.55 |
|
G1CL16 |
250000 |
1000 |
200-280 |
282-470 |
680 |
595 |
465 |
52.22 |
|
G1CL17 |
280000 |
980 |
220-300 |
282-470 |
720 |
645 |
495 |
69 |
|
G1CL18 |
355000 |
900 |
240-320 |
330-470 |
775 |
675 |
520 |
96.16 |
|
G1CL19 |
450000 |
830 |
260-340 |
330-550 |
815 |
715 |
560 |
115.6 |
|
G1CL20 |
500000 |
790 |
280-360 |
380-550 |
855 |
755 |
585 |
167.41 |
|
G1CL21 |
630000 |
750 |
300-380 |
380-550 |
915 |
795 |
620 |
215.7 |
|
G1CL22 |
710000 |
720 |
340-400 |
450-650 |
960 |
840 |
665 |
278.07 |
|
G1CL23 |
800000 |
680 |
360-420 |
450-650 |
1010 |
890 |
640 |
397.4 |
|
G1CL24 |
100000 |
650 |
380-450 |
450-650 |
1050 |
925 |
730 |
448.1 |
|
G1CL25 |
112000 |
610 |
400-480 |
540-650 |
1120 |
970 |
770 |
564.64 |
|
G1CL26 |
125000 |
580 |
420-500 |
540-650 |
1160 |
990 |
800 |
637.4 |
|
G1CL27 |
140000 |
560 |
450-530 |
540-800 |
1210 |
1060 |
850 |
866.26 |
|
G1CL28 |
160000 |
540 |
480-560 |
540-800 |
1250 |
1080 |
890 |
1020.76 |
|
G1CL29 |
240000 |
520 |
500-600 |
540-800 |
1340 |
1200 |
960 |
1050.84 |
|
G1CL30 |
280000 |
500 |
530-680 |
680-800 |
1390 |
1240 |
1005 |
1947.14 |
|
| |
|
