型号 |
公称转矩
Tn N.m |
轴孔直径
d1,d2 |
轴孔长度
L |
D |
D1 |
D2 |
D3 |
D4 |
B |
B1 |
H
min |
转动惯量
（kg.m2） |
|
ⅠⅡ |
|
WGT1 |
710 |
12-42 |
32-112 |
122 |
115 |
98 |
88 |
60 |
58 |
50 |
|
|
|
|
WGT2 |
1250 |
22-56 |
52-112 |
150 |
145 |
118 |
108 |
77 |
68 |
52 |
|
|
|
|
WGT3 |
2500 |
22-63 |
52-142 |
170 |
165 |
140 |
125 |
90 |
80 |
54 |
|
|
|
|
WGT4 |
4500 |
30-80 |
82-172 |
200 |
195 |
160 |
145 |
112 |
90 |
58 |
|
|
|
|
WGT5 |
7100 |
30-90 |
82-172 |
225 |
215 |
180 |
168 |
128 |
100 |
63 |
|
|
|
|
WGT6 |
10000 |
32-100 |
82-212 |
245 |
230 |
200 |
185 |
145 |
112 |
67 |
|
|
|
|
WGT7 |
14000 |
32-110 |
82-212 |
272 |
265 |
230 |
210 |
160 |
122 |
74 |
|
|
|
|
WGT8 |
20000 |
55-125 |
107-212 |
290 |
272 |
245 |
225 |
176 |
136 |
81 |
|
|
|
|
WGT9 |
25000 |
65-140 |
107-252 |
315 |
305 |
265 |
245 |
190 |
140 |
88 |
|
|
|
|
WGT10 |
40000 |
75-160 |
132-302 |
355 |
340 |
300 |
280 |
225 |
165 |
98 |
|
|
|
|
WGT11 |
56000 |
85-180 |
167-302 |
412 |
385 |
345 |
325 |
256 |
180 |
112 |
|
|
|
|
WGT12 |
80000 |
120-200 |
167-352 |
440 |
435 |
375 |
360 |
288 |
210 |
125 |
|
|
|
|
WGT13 |
112000 |
140-220 |
202-352 |
490 |
480 |
425 |
400 |
320 |
235 |
136 |
|
|
|
|
WGT14 |
160000 |
160-260 |
242-410 |
545 |
540 |
462 |
440 |
362 |
265 |
158 |
|
|
|
|
WGT15 |
224000 |
160-280 |
242-470 |
580 |
- |
488 |
- |
385 |
280 |
- |
|
|
|
|
WGT16 |
280000 |
180-300 |
242-470 |
650 |
- |
560 |
- |
440 |
300 |
- |
|
|
|
|
WGT17 |
355000 |
200-320 |
282-470 |
690 |
- |
600 |
- |
460 |
325 |
- |
|
|
|
|
WGT18 |
450000 |
220-360 |
282-550 |
750 |
- |
650 |
- |
510 |
350 |
- |
|
|
|
|
WGT19 |
560000 |
240-380 |
330-550 |
775 |
- |
690 |
- |
535 |
372 |
- |
|
|
|
|
WGT20 |
710000 |
260-400 |
330-650 |
825 |
- |
730 |
- |
580 |
392.5 |
- |
|
|
|
|
WGT21 |
800000 |
280-440 |
380-650 |
925 |
- |
825 |
- |
620 |
405 |
- |
|
|
|
|
WGT22 |
900000 |
320-460 |
380-650 |
950 |
- |
850 |
- |
665 |
410 |
- |
|
|
|
|
WGT23 |
1000000 |
360-500 |
450-650 |
1030 |
- |
900 |
- |
710 |
440 |
- |
|
|
|
|
WGT24 |
1250000 |
380-520 |
450-800 |
1060 |
- |
925 |
- |
730 |
450 |
- |
|
|
|
|
| |
|
